3 in 1 Generator Welding Air Compressor PWC 7.0-200A

€ 9.680,00

exclusief btw / € 11.712,80 inclusief btw
Adviesprijs

The 3 in 1 Generator Welding Air Compressor 6,3 KVA – 7 KVA is run by a 9KW Swedic outdoor series engine and a two stage al cast iron pressure lubed pump!
This unit will provide 8 bar compressed air, two power outlets 230V 16A – 230V 32A and a 200AMP welder, ideal for any job site. Use this 3 in 1 system in commercial and industrial applications on a jobsite or on the go whit its solid pneumatic tires. The tires can be removed to make this unit stationary as well. The two stage all cast iron pressure lubed pump delivers high CFM output and reliability. The two ASME twin thanks provide 20L of air storage,quick disconnects,rubber isolator pads, and filled gauges, plus heavy duty steel belt guard to make this unit ready for any task.


Description Specification
Duty Cycle 50%
OCV (V) DC75
Current range (A) DC 50-200
Welding voltage (V) DC 22-28V
Welding rod 1.6-4.0 mm
Rated current/voltage (A/V) 180A/27.2V
Auxiliary rated power output 5000W-6.3 KVA 230V 5500W-7 KVA
Engine Model Swedic 420
Max.power/Speed(RPM) 9.0KW/3600rpm
Displacement(cc) Gas,420
Start method E-start
Air Capacity (L) 20
Stage 1
Flow 60-70L/min
Pressure range 0.6-0.8 Mpa
Fuel tank Capacity (L) 30
Protection class IP23
Dimension (mm) 850,5*583*780
Net Weight (kg) 150
Gross Weight (kg) 164
Sockets 1*32A/230V European Industrial Socket. 1*16A/230V two-hole European Socket

PWC 7.0-200A
